Model: e273f-bk
$339.00 USD
LED backlight technology provides for industry-leading low power consumption and less hazardous materials Height-adjust, dual direction pivot, tilt and swivel capabilities are designed to fit every work environment Full digital connectivity, including DisplayPort, HDMI and USB Type-C inputs Securely mount zero or thin clients with the included mounting plate Touch-sensitive OSD® controls are integrated into the bezel, making display adjustments easier than ever ECO Mode™ allows you to manually adjust the display’s brightness to your liking, saving power and reducing your energy costs ENERGY STAR 8.0 and TCO 8.0 NaViSet Administrator 2: Free software solution that greatly eases administration and management of larger display device installations
  • Viewing without interruption.The 27” NEC MultiSync E273F-BK is an ultra narrow LED-backlit desktop monitor ideal for corporate environments. Designed to enhance work performance, this widescreen model features IPS panel technology with wide viewing angles (178° horizontal/vertical) and ergonomic adjustability including dual-direction pivot. The LED backlighting of the E273F-BK allows for a slimmer profile, lighter weight and increased power savings and the unique thin bezel design is only 1mm thick. Securely mount zero or thin clients with the included mounting plate. The comprehensive digital only input panel, including DisplayPort, HDMI and USB Type-C, connects with the latest peripherals with digital connections and future-proofs your investment.
  • ENERGY STAR 8.0 and TCO 8.0
  • NaViSet Administrator 2: Free software solution that greatly eases administration and management of larger display device installations



Legal Disclaimer To California Residents
WARNING: This product can expose you to chemicals including Styrene and Formaldehyde (gas), which are known to the State of California to cause cancer, and Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov


Display

Panel Technology IPS Viewable Image Size 27 "
Aspect Ratio 16:9 Native Resolution 1080x1920
Pixel Pitch 0.31 mm Pixels Per Inch 82 @ native resolution
Backlight Type LED Brightness (typical) 250 cd/m2
Contrast Ratio (typical) 5000:1 Viewing Angle (typical) 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Response Time (typical) 6 ms Active Screen Area 579.9 x 336.3mm
Displayable Colors More than 16.7 million Color Gamut
Adobe RGB Coverage/Size:
75.3
NTSC Coverage/Size:
72
sRGB Coverage/Size:
101.6

Synchronization Range

Horizontal (Analog/Digital) 31.5-83.0 KHz Vertical ~50 - ~75 Hz

Input Signal

Video Analog RGB 0.7 Vp-p/75 Ohms

Signal Compatibility/Connectivity

Video Analog RGB 0.7 Vp-p/75 Ohms DisplayPort, HDMI, USB Type-C
Input Terminals
Digital:
DisplayPort, HDMI, USB Type-C
Connectors:
DisplayPort, HDMI, USB Type-C
RGB1(analog):
VGA
RGB1(digital):
HDMI
RGB2(digital):
DisplayPort
RGB3(digital):
USB Type-C
Audio 1:
DisplayPort
Audio 2:
HDMI
Audio 3:
USB Type-C
Output Terminals
Audio Out:
Stereo Mini Jack

Power Consumption (typical)

On 18W Power Savings Mode 0.36 W

Physical Specifications

Bezel Width (Left/Right, Top/Bottom) 0.04 in./0.04 in., 0.04 in./0.63 in. : 1 mm/1 mm, 1 mm/16.1 mm Dimensions (WxHxD)
With stand:
24.0 x 15.4 - 20.5 x 11.0 in. / 610.7 x 391.7 - 521.7 x 278.7 mm
Without stand:
24 x 14.2 x 2 in. / 610.7 x 360.3 x 51.8 mm
Shipping:
28.74 x 18.70 x 8.03 in. / 730.0 x 475.0 x 204.0 mm
Weight
Net Weight (with stand):
18.5 lbs. / 8.4 kg
Net Weight (without stand):
12.6 lbs. / 5.7 kg.
Shipping:
24.9 lbs. / 11.3kg
VESA Hole Configuration 100 x 100mm

Environmental Conditions

Operating Temperature 41-95°F / 5-35°C Operating Humidity 20-80%
Operating Altitude 16,404 ft. / 5000m Storage Temperature 14-140°F / -10-60°C
Storage Humidity 10-85% Storage Altitude 40,000 ft. / 12,192m

Environmental Compliance

ENERGYSTAR 8.0 RoHS Yes
TCO 8.0

Limited Warranty (parts & labor)

3 years

Additional Features

  • ECO Mode
  • Carbon footprint meter
  • Ultra Narrow Bezels
  • Tilt
  • Carrying handle
  • Audio input
  • Headphone output
  • Rapid Response
  • Ambix
  • XtraView
  • OSD® user controls
  • OSD Lock Out
  • Cable management
  • NaViSet™ Administrator 2
  • VESA mount
  • HDCP
  • DDC/CI
  • No Touch Auto Adjust
  • Plug and Play (VESA DDC 2B)
  • VESA DPMS power management
  • Energy Star 8.0
  • TCO 8.0
  • Dynamic Video Mode
  • Digital controls
  • ISO 9241-307 Class I
  • Low Blue Light
  • Flicker Free


LED Backlight
Provides for industry-leading low power consumption and less hazardous materials.
Ambix®
Allows up to two inputs (VGA and DVI-I) to be connected to a single monitor and for each of the three signals to be displayed with the press of a button.
No Touch Auto Adjust™
Allows the monitor to be automatically adjusted to optimal image settings when initially turned on.
XtraView®
Delivers wide viewing angles of up to 176º horizontally and vertically (up to 88º up, down, left and right) without any glare, reflection or distortion.
1080p native resolution (1920x1080)
High resolution provides detailed display of text, graphics and images. HD video is displayed in 16:9 wide aspect ratio.
